Dimensions:
Width: 2.150 mm
Height: 3.700 mm
Wheelbase: 1310 mm
Empty weight: 12,500 kg ± 5%
(Depends on selected equipment)
Capacity:
Geometric volume: 25 ~ 45 m³ (optional)
Tank:
Transported products: anhydrous ammonia (NH3)
Operating temperature: -40°C + 50°C
Design pressure: 19.3 bar
Test pressure: 29 bar
Frame:
Cylindrical cross section in accordance with EN 14025 design standard.
High-strength, imported, special material for "P" series pressure vessels in accordance with EN 10028-3.
The V-type consoles used in the chassis connections are welded to the body, cushioned to increase body strength, and bolted to the chassis.
In the event of a possible tipping, a drain hole on the horizontal axis on the right or left to ensure complete emptying of the tanks.
Luke:
Conforms to EN 14025, 1 piece 16" diameter, mounted on the back bend of the body, bolted to a flange welded to the tank body.
Options:
Fixed pressure gauge installed in accordance with standard EN 14025 pressure calculations.
Glycerine manometer showing the pressure inside the tank.
Thermometer showing the temperature inside the tank.
Magnetic level indicator of the product in the tank.
Safety valve.
